Disc Brakes with Hydraulic command for Planetary Motors
Brand
M + S HYDRAULIC
Service phone
+(30) 2310 752 773
Μodel LB 288 for motor series EPM, EPRM & EPMS
| LB / 288.. | 7 | 14 | 21 | 32 | 43 | 63 |
| Min στατική ροπή (daNM) | 6-8 | 13-15 | 20-22 | 31-33 | 42-44 | 62-64 |
| Min pressure (bar) | 4-5 | 8-9 | 12-13 | 18-20 | 24-26 | 38-39 |
| Max pressure (bar) | 300 | |||||
| Min oil quantity for brake release (cm3) | 7-8 | |||||
| oil quantity (cm³) | 50 – 120 | |||||
Μοdels for motors series EPMT, EPMV
| LB / 289.. | 21 | 32 | 43 | 63 | L43 | L63 |
| Min torque (daNM) | 20-22 | 31-33 | 42-44 | 62-64 | 41-45 | 62-64 |
| Min pressure (bar) | 12-13 | 18-20 | 24-26 | 37-39 | 20-22 | 21-23 |
| Max pressure (bar) | 300 | |||||
| Min oil for brake release (cm3) | 7-8 | |||||
| Oil quantity (cm³) | 50 – 120 | |||||
